Heat sealing tester

800 USD ($)/Unit

Get a Price/Quote

Product Details:

Interface Type RS232/USB
Display Type LCD digital display
Mounting Type Bench-top
Application Determination of heat-sealing properties for plastic film, laminated film, coating materials, flexible packaging, and more
Humidity 20~70% RH
Port Size 6 mm gas connector
Measuring Range 0~1500 N
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Heat sealing tester Price And Quantity

Minimum Order Quantity 1 Unit
Price 800 USD ($)/Unit

Operating Environment 10C~40C, non-corrosive atmosphere
Seal Pressure 0.15~0.7 MPa (adjustable)
Safety Protection Automatic power-off, overheat alarm
Sealing Surface Type Flat or patterned (customizable)
Heated Bar Material Anodized aluminum
Compliance Meets ASTM F2029, GB/T 7790, YBB 00122003-2015 standards
Sealing Time 0.1~99.9 s, programmable
Dimension (LWH) 520350430 mm
Heating Up Time 10 min to max temp
Data Output PC connectivity for result export

Heat sealing tester Product Specifications

Interface Type RS232/USB
Display Type LCD digital display
Mounting Type Bench-top
Humidity 20~70% RH
Port Size 6 mm gas connector
Application Determination of heat-sealing properties for plastic film, laminated film, coating materials, flexible packaging, and more
Gas Pressure 0.5 MPa
Measuring Range 0~1500 N
Specimen Size (30-300) mm length (5-30) mm width
Power Supply AC 220V, 50Hz
Test Stroke 10~100 mm
Resolution 0.1 N
Frequency 50 Hz
Accuracy 1% F.S.
Automation Grade Semi-automatic
Control Mode Microcomputer-controlled, touch interface
Test Width 5~30 mm
Equipment Type Heat Sealing Tester
Max Height 350 mm (sealing bar stroke)
Test Range 0~1500 N
Operating Voltage AC 220V, 50Hz
Temperature Room temperature to 300C (adjustable)
Response Time 500 ms
Features Digital display, precise heating control, over-temperature and pressure protection, programmable settings
Usage Lab/Industrial testing
Number of Specimens 1~3 at once
Machine Weight 28 kg
Capacity Standard (customizable as per requirement)
Test Speed 300 mm/min (default), adjustable

Operating Environment 10C~40C, non-corrosive atmosphere
Seal Pressure 0.15~0.7 MPa (adjustable)
Safety Protection Automatic power-off, overheat alarm
Sealing Surface Type Flat or patterned (customizable)
Heated Bar Material Anodized aluminum
Compliance Meets ASTM F2029, GB/T 7790, YBB 00122003-2015 standards
Sealing Time 0.1~99.9 s, programmable
Dimension (LWH) 520350430 mm
Heating Up Time 10 min to max temp
Data Output PC connectivity for result export

Heat sealing tester Trade Information

FOB Port Shenzhen
Payment Terms Letter of Credit (L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Cash on Delivery (COD), Letter of Credit at Sight (Sight L/C), Delivery Point (DP), Cash Against Delivery (CAD), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)
Supply Ability 30 Unit Per Month
Delivery Time 15 Days
Packaging Details Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Main Export Market(s) Australia, North America, Eastern Europe, Western Europe, Africa, Middle East, South America, Asia, Central America
Certifications CE,ISO

Product Description

Heat sealing tester HD-R828

THE USAGE:

Applied to plastic films,plastic composite films,paper-plastic composite films,coextruded films,aluminized films,aluminum foils,aluminum foil composite films and many others. Heat sealing surface should be smooth and width can be designed based on user requirement.

Standards:ASTM F2029,YBB 00122003.

Parameters:

Sealing temperature:room temperature~300
Accuracy:0.2
Dwell time:0.1~999.9s
Sealing pressure:0.05mpa~0.7mpa
Sealing area:330mm*10mm(can be customized)
Heating mode:single heating surface or double heating
Gas supply pressure:0.5mpa~0.7mpa(customer supply)
Port size:6mm tubing
Instrument dimension:536mm*335mm*413mm(L*W*H)
Power supply:AC 220V 50Hz

Advanced Precision & Robust Control

This heat sealing tester leverages microcomputer control with a responsive touch interface, allowing users to fine-tune sealing temperature, time, and pressure for optimal repeatability. Anodized aluminum heated bars provide stable and uniform heating, and programmable settings enable tailored test parameters to suit a wide range of film and laminate materials. Digital data output enhances traceability of results.

Safety & Compliance Built Into Every Test

Intelligent safety systemssuch as automatic power-off and temperature alarmswork in tandem with protective housing for operator safety. The equipment meets prominent industry standards (ASTM F2029, GB/T 7790, YBB 00122003-2015), making it suitable for quality control and research across various industrial sectors, including packaging and film manufacturing.

Versatility for Multiple Applications

Accommodating up to three specimens simultaneously, this tester adapts to different material types, specimen dimensions, and test needs. The adjustable speed, force, and sealing area options make it an indispensable tool for labs and industrial environments looking to verify or optimize heat-sealing parameters for flexible packaging materials.

FAQs of Heat sealing tester:

Q: How do I adjust the sealing parameters for different materials using the Heat Sealing Tester?

A: You can easily set sealing temperature (room temp to 300C), pressure (0.150.7 MPa), sealing time (0.199.9 s), and test width (530 mm) directly from the intuitive touch interface. Multiple programmable presets allow you to customize test cycles for various film or laminated materials.

Q: What types of packaging materials can this tester be used for?

A: This equipment is suitable for plastic films, laminated films, coated materials, and other flexible packaging substrates. Its versatile sealing surface options (flat or patterned) and wide temperature and pressure ranges support diverse materials compliance testing.

Q: When is it necessary to perform heat-sealing tests on packaging materials?

A: Heat-sealing tests are essential during new material development, quality control, and production audits to ensure package integrity, compliance with ASTM/GB/T/YBB standards, and to optimize sealing parameters for durable, leak-proof packaging.

Q: Where can I access and export the heat-sealing test results?

A: Test data can be exported to a PC through RS232 or USB connectivity, enabling comprehensive analysis, report generation, and data archiving for regulatory or quality audit purposes.

Q: What is the process for operating the heat sealing tester safely?

A: Begin by selecting and placing specimens (30300 mm 530 mm) on the mounting area. Set the sealing parameters, then initiate the test. The instrument features automatic power-off and overheat alarms to prevent accidents, ensuring safe operation throughout testing.

Q: How does using this heat sealing tester benefit my laboratory or production line?

A: The tester delivers accurate, repeatable data with a high level of automation and safety, supporting efficient research, reliable quality control, rapid parameter optimization, and compliance verification. Its programmable features and high-precision measurement enhance workflow efficiency for both R&D and routine testing.
