Computer servo carton compression tester
1500 USD ($)/Unit
Product Details:
- Frame Type Heavy-duty welded steel frame
- Gauge Load cell type
- Capacity 0-50 kN
- Usage & Applications Carton compression test, box strength test, packaging industries
- Control Mode Computer & Servo Control
- Product Type Computer Servo Carton Compression Tester
- Power 2200 W
- Click to View more
X
Computer servo carton compression tester Price And Quantity
- 1 Unit
- 1500 USD ($)/Unit
- Multi-language software interface
- 1200 x 1200 x 1200 mm
- 1 N
- Conforms to TAPPI, ISO, ASTM standards
- Computer controlled with servo motor system
- Overload protection, Emergency stop
- 10C 35C
- 20% 80% RH
- Corrugated cartons, boxes, packaging materials
- Automatic or Manual
- USB, Ethernet
- Windows-based control software
Computer servo carton compression tester Product Specifications
- Approx. 650 kg
- 10-200 mm/min (adjustable)
- Digital (LCD & PC Display)
- 1200 x 1200 x 1800 mm
- 0-600 mm
- 1% F.S.
- 2200 W
- Computer Servo Carton Compression Tester
- Blue & White
- AC 220 V, 50 Hz
- Computer & Servo Control
- Single Phase
- Carton compression test, box strength test, packaging industries
- 0-50 kN
- Load cell type
- Heavy-duty welded steel frame
- 220 V
- Highly precise measuring, data storage & print function, automatic return, overload protection
- 2200 W
- Automatic
- 50 Hz
- Multi-language software interface
- 1200 x 1200 x 1200 mm
- 1 N
- Conforms to TAPPI, ISO, ASTM standards
- Computer controlled with servo motor system
- Overload protection, Emergency stop
- 10C 35C
- 20% 80% RH
- Corrugated cartons, boxes, packaging materials
- Automatic or Manual
- USB, Ethernet
- Windows-based control software
Computer servo carton compression tester Trade Information
- Shenzhen
- Cash on Delivery (COD), Letter of Credit at Sight (Sight L/C), Paypal, Letter of Credit (L/C), Western Union, Delivery Point (DP), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)
- 30 Unit Per Month
- 15 Days
- Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
- Australia, North America, Eastern Europe, Western Europe, Africa, Central America, Middle East, South America, Asia
- CE,ISO
Product Description
Computer servo control carton compression tester
The usage:
Carton compression tester is used for measuring the compression strength of corrugated carton,shipping container or other packaging containers, and may do hold pressure Stacking test. Test results can be plant stack finished packing a high degree of important reference, or an important basis for the design box.
Features:
The usage:
Carton compression tester is used for measuring the compression strength of corrugated carton,shipping container or other packaging containers, and may do hold pressure Stacking test. Test results can be plant stack finished packing a high degree of important reference, or an important basis for the design box.
Features:
- Four highly precise sensors, more accurate;
- Panasonic servo motor, imported ball screw rod;
- Four experimental methods are provided: Constant pressure deformation,Shape-varying
- resistance to compression, Maximum crushing force and Stacking strength test.
- Computer control system, can show the compression force, displacement and other
- curves.And the results data can be directly output by word report in intuitive.
- Own factory, professional pre-sales engineer and after-sales service.
- Using a single-screen operation; do not need to switch the screen.
- With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily.
| Model | HD-A505S-1500 |
| Capacity | 5000Kgf |
| Resolution | 1/250.000 |
| Unit | Kg,Lb,N Switching function |
| Report item | Peak,average,set the value of holding pressure,and can be printed |
| Test apace(L*W*H)mm | 1300*1500*1500 |
| Structure | Computer control system,Panasonic servo motor,imported ball screw rod |
| Test speed | 103mm/min |
| Outside Dimension(L*W*H)mm | 2000*1500*2030 |
| Weight | About 1340Kg |
| Power | 1220v/50Hz |
| Features | Four high precise sensors,more accurate |
Standards
TAPPI-T804 , JIS-20212 , ASTM-D642 , QB/T1048 , BS EN ISO 12048 ,
Advanced Servo-Controlled Performance
Utilizing a computer-controlled servo motor system, this tester delivers superior compression force application and consistent results. The automatic or manual clamping options optimize flexibility during testing, while speed ranges from 10 to 200 mm/min cater to varied test requirements for packaging materials.
Versatile and Precise Measurements
With a generous test space and high-resolution measurement of 1 N, the tester accommodates cartons up to 1200 x 1200 x 1200 mm. Its 1% accuracy and cutting-edge load cell technology ensure dependable data for manufacturers, exporters, and retailers focused on packaging durability.
Integrated Data Management
Results are conveniently managed through USB or Ethernet connections. The Windows-based software supports multiple languages, providing easy data recording, storage, and printing, essential for comprehensive quality control documentation.
FAQs of Computer servo carton compression tester:
Q: How does the computer servo carton compression tester operate?
A: The tester uses a servo motor system managed by Windows-based control software. It applies compressive force to carton samples, measuring their resistance and deformation with high precision. Automatic and manual clamping options, along with adjustable speed and real-time digital display, ensure precise control and versatility for various testing requirements.Q: What types of materials and applications is this tester suitable for?
A: It is specifically designed for corrugated cartons, boxes, and a range of packaging materials. Suitable for quality assessment in packaging industries, it performs carton compression and box strength tests that align with international standards such as TAPPI, ISO, and ASTM.Q: When should I use the compression tester in the packaging process?
A: Use the tester during product development, quality assurance, and routine inspection phases to confirm the structural strength and durability of your packaging materials before shipping goods. This ensures compliance with industrial standards and reduces the likelihood of product damage.Q: Where can I access and manage test data from the machine?
A: Test data is available via a digital LCD and computer display. You can export results through USB or Ethernet, and utilize the Windows-based software for comprehensive data management, storage, analysis, and printing.Q: What is the process for conducting a carton compression test?
A: Simply position the carton or packaging sample in the designated test area, select appropriate settings via the control software, and initiate the test. The servo-controlled system applies pressure while recording data, then returns to the home position automatically after completion.Q: How do safety features benefit operators?
A: The machine incorporates overload protection and an emergency stop button to ensure operator safety during testing. These features safeguard both users and equipment, providing confidence and compliance with industry safety protocols.Q: What advantages does this tester offer over conventional models?
A: It provides enhanced accuracy, real-time data handling, automatic controls, multi-language software support, and compliance with key standards. These features improve test efficiency, reliability, and documentation for anyone in the packaging supply chain.Tell us about your requirement
