Compression Foam Testing Equipment
4000 USD ($)/Set
Product Details:
- Mounting Type Floor mounted
- Response Time <1 second
- Accuracy 1% of reading
- Automation Grade Semi-automatic
- Measuring Range 0~3000 N
- Port Size Standard
- Hardness As per foam hardness test standards
- Click to View more
X
Compression Foam Testing Equipment Price And Quantity
- 4000 USD ($)/Set
- 1 Set
- Polished stainless steel
- Strain gauge based
- <65 dB
- Computer connectivity for result storage
- Emergency stop, limit switch protection
Compression Foam Testing Equipment Product Specifications
- 400 mm
- 6 bar max
- Foam compression testing for quality and durability assessment
- 50 Hz
- As per foam hardness test standards
- Standard
- Digital microprocessor based
- 0~3000 N
- 1% of reading
- Semi-automatic
- <1 second
- Floor mounted
- 0.01 N
- 220V 10%
- Compression Foam Testing Equipment
- Automatic peak hold, overload protection, programmable test cycles
- Approx. 150 kg
- 380 mm x 380 mm
- Digital LCD display
- 50-300 mm/min (adjustable)
- 5 kN
- 300 mm (adjustable platen separation)
- 0~3000 N
- Industrial quality control
- 0-300 mm
- 10C to 40C
- USB/RS232
- Single specimen at a time
- 220V AC, 50Hz, single phase
- Less than 85% RH (non-condensing)
- Polished stainless steel
- Strain gauge based
- <65 dB
- Computer connectivity for result storage
- Emergency stop, limit switch protection
Compression Foam Testing Equipment Trade Information
- Shenzhen
- 10-30 Set Per Month
- 1 Week
- Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
- CE,ISO
Product Description
The usage:
It determines the thickness and hardness vale of porous elastic materials. With different loads the foams are tested to measure their indention. Our product is available in various specifications according to the need of the clients
STANDARD FEATURES
| Item | Description |
| Max. Force | 2000 kg (20KN) |
| Load cell | Germany brand load cell for high accuracy |
| Control system | PC with windows 7 system |
| Motor | Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod |
| Force reading | kgf, Ibf, N, KN, T etc |
| Stoke | 1100mm including fixture |
| Load cell Resolution | 1/250,000 |
| Load Precision | within 0.5% |
| Test speed | 0.01~500mm/min (adjustable) |
| Software | TM 2101 |
| Curves display | Load- elongation, Elongation-time, Time-elongation, Stress-strain |
| Data display | Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc |
| Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
Advanced Measurement Accuracy
Employing strain gauge-based load cell technology, this equipment delivers high measurement accuracy (1% of reading) with rapid response time (<1 second) and fine resolution (0.01 N). This ensures reliable data for foam hardness and compression quality assessment as per industry standards.
Enhanced Safety and User Convenience
The machine integrates vital safety measures, such as emergency stop and limit switch protection. The semi-automatic digital microprocessor system offers easy operation, programmable test cycles, overload protection, and digital data output, enhancing user convenience and workplace safety during industrial quality control.
FAQs of Compression Foam Testing Equipment:
Q: How does the compression foam testing equipment operate for foam quality assessment?
A: The equipment uses a strain gauge-based load cell and a polished stainless steel test plate to compress individual foam specimens. The digital microprocessor control allows for programmable test cycles and adjustable test speed, providing precise measurement of foam durability and hardness, with data displayed on the LCD and stored on a computer.Q: What safety features are present to ensure secure operation during testing?
A: To protect users and samples, the equipment incorporates an emergency stop button and limit switch protection. These features promptly halt operation or prevent overextension, minimizing risk during compression testing activities.Q: When should you use this foam compression tester in your industrial process?
A: This equipment is best used during quality control or R&D stages of foam product manufacturing. It verifies compliance with hardness and durability standards, ensuring products meet both internal benchmarks and regulatory specifications before shipment or further processing.Q: Where can the compression foam testing equipment be installed for optimum performance?
A: The device is designed for floor mounting in environments where humidity is below 85% RH and temperatures range from 10C to 40C, such as industrial labs or quality assurance departments. Standard port sizing and simple power requirements facilitate installation in most manufacturing facilities.Q: What benefits does this machine offer for industrial foam testing applications?
A: Users benefit from high precision (1% accuracy), fast response (<1 second), digital data recording, and automated test cycles. Easy data transfer through USB/RS232 interfaces and safety protections make it reliable for consistent foam quality evaluation, improving process control and product reliability.Q: How is test data managed and stored by this equipment?
A: During each test, results are displayed instantly on the digital LCD and can be exported via computer connectivity (USB or RS232) for long-term storage, analysis, and reporting. This facilitates traceability and supports thorough documentation required for quality audits.Q: What specimen size and test capacity does the equipment support?
A: The machine is engineered for testing single foam specimens measuring 380 mm x 380 mm, with a maximum compression capacity of 5 kN and a test range of 0 to 3000 N, suitable for most industrial foam analysis applications.Tell us about your requirement
