Anti-yellowing aging tester

3000.00 - 6000.00 USD ($)

Get a Price/Quote

Product Details:

Humidity <65% RH
Operating Voltage 220V
Display Type Digital LCD
Accuracy 0.5C
Measuring Range Adjustable (up to 200C)
Temperature Room temp. to 200C (adjustable)
Gas Pressure No external gas required
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Anti-yellowing aging tester Price And Quantity

Minimum Order Quantity 1 Set
Price Range 3000.00 - 6000.00 USD ($)

Material of Chamber High-grade stainless steel
Safety Features Over-temperature protection, fuse protection, automatic power cut-off
Timer Range 0~999.9 hours
Internal Dimensions 450350450 mm
Sample Holder Adjustable clips provided
Warm-up Time Approx. 10 min
Light Source UV simulation capability
External Dimensions 750650850 mm
Test Methods Conforms to ASTM and ISO standards
Noise Level 55 dB(A)
Viewing Window Heat-resistant glass

Anti-yellowing aging tester Product Specifications

Response Time Instant
Mounting Type Desktop
Usage Accelerated aging and yellowing testing
Equipment Type Anti-Yellowing Aging Tester
Specimen Size 75150 mm or as required
Capacity Suits multiple materials
Test Range 0~200C
Test Width 40 mm
Number of Specimens 2-6
Max Height 350 mm
Control Mode Digital programmable control
Interface Type User-friendly keypad
Application For anti-yellowing and aging test of rubber, leather, plastic, and other materials
Test Stroke 60 mm
Port Size Standard (customizable)
Resolution 0.1C
Machine Weight Approx. 80 kg
Power Supply AC 220V/50Hz
Frequency 50/60 Hz
Gas Pressure No external gas required
Temperature Room temp. to 200C (adjustable)
Automation Grade Semi-automatic
Features Automatic alarm, digital timer, overheat protection
Humidity <65% RH
Operating Voltage 220V
Test Speed 605 cycles/min
Measuring Range Adjustable (up to 200C)
Accuracy 0.5C
Display Type Digital LCD

Material of Chamber High-grade stainless steel
Safety Features Over-temperature protection, fuse protection, automatic power cut-off
Timer Range 0~999.9 hours
Internal Dimensions 450350450 mm
Sample Holder Adjustable clips provided
Warm-up Time Approx. 10 min
Light Source UV simulation capability
External Dimensions 750650850 mm
Test Methods Conforms to ASTM and ISO standards
Noise Level 55 dB(A)
Viewing Window Heat-resistant glass

Anti-yellowing aging tester Trade Information

FOB Port shenzhen
Supply Ability 1-10 Set Per Month
Delivery Time 30 Days
Packaging Details Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

Product Description

Anti-yellowing aging tester

Function:

Anti-yellowing aging testercan promote the increase of sulfur rubber deterioration, to calculate the change rate of tensile and elongation before and after heat. Its generally thought that test for one day at 70C, in theory as exposed to the atmosphere for 6 months.

Anti-yellowing: Anti-yellowing aging tester stimulates the atmosphere environment, driven by the sun ultraviolet radiation. Its generally thought that the appearance change at 50C for 9 hours, in theory as exposed to atmosphere for 6 months.

Features:

To simulate outdoor weathering, the UV aging testersexposes materials to alternating cycles of UV light and moisture at controlled, elevated temperatures. It simulates the effects of sunlight using special fluorescent UV lamps. It simulates dew and rain with condensing humidity and/or water spray.

The UV accelerated weathering tester is the simplest, most reliable, and easiest to use weathering tester available. With thousands of testers in use worldwide, it is the worlds most widely used weathering tester.
The UV accelerated weathering tester is the simplest, most reliable, and easiest to use weathering tester available. With thousands of testers in use worldwide, it is the worlds most widely used weathering tester.

Structure:

The inner bladder of the chamber is made of imported high-class stainless steel plate while the outer bladder is made of A3 steel plate sprayed with plastic.
The heating mode adopts inner bladder trough type heating with its rapid temperature rise and even temperature distribution.

Control System:

Adopts black aluminum plate to connect temperature sensor and adopts black board temperature meter to control heating so as to ensure more stable temperature.
The radiometer probe is fixed so as to avoid the frequent installation and disassembly.
The radiation quantity adopts the special UV irradiatometer with high-precision display and measurement.

Comprehensive Material Testing

This tester supports a wide range of materials and specimen sizes, enabling laboratories, manufacturers, and suppliers to conduct precise anti-yellowing and aging tests on rubber, plastics, leather, and more. The adjustable test parameters and specimen holders cater to different requirements, ensuring versatile applicability.

Advanced Safety & Control Features

Safety and reliability are assured with built-in over-temperature protection, fuse safeguards, automatic power cut-off, and an automatic alarm system. The digital programmable control, quick warm-up, and instant LCD response enable efficient, accurate testing while minimizing user risk during operation.

Conformance & Automation

Designed to comply with international ASTM and ISO standards, this semi-automatic desktop tester provides robust, repeatable results. Its automation grade streamlines aging and yellowing processes, with easy-to-set digital timer, programmable cycles, and user-friendly interface, supporting accelerated and reliable material assessment.

FAQs of Anti-yellowing aging tester:

Q: How does the Anti-Yellowing Aging Tester perform accelerated aging and yellowing tests on materials?

A: The tester uses a high-grade stainless steel chamber equipped with UV simulation capability and adjustable temperature (up to 200C) to mimic environmental aging and yellowing processes. Specimens are exposed to controlled cycles and temperatures, with digital programmable control managing test conditions and duration.

Q: What types of materials and specimen sizes can be tested with this equipment?

A: It is suitable for rubber, leather, plastic, and similar materials. Specimen sizes can typically range from 75150 mm, with the adjustable sample holder accommodating between 2 and 6 samples simultaneously, offering flexibility for varied testing needs.

Q: When should I use this tester for material evaluation?

A: The Anti-Yellowing Aging Tester should be used during product development, quality control, and compliance verification phases when assessing the longevity and color stability of materials exposed to environmental factors and UV light.

Q: Where can this tester be installed and operated safely?

A: Its compact desktop mounting and low noise emission ( 55 dB(A)) allow installation in laboratories, manufacturing facilities, and quality assurance departments. Safety features like over-temperature and fuse protection ensure safe operation in professional environments.

Q: What is the process for setting up a test with the Anti-Yellowing Aging Tester?

A: Users place specimens in adjustable clips inside the chamber, program the test parameterstemperature, timer, cyclesusing the digital keypad, and initiate the warm-up (about 10 minutes). The system automates test execution and provides alerts upon completion or in case of abnormal conditions.

Q: How does using this tester benefit manufacturers and suppliers?

A: By providing accurate, repeatable tests compliant with ASTM and ISO standards, manufacturers and suppliers can reliably evaluate material durability, predict product longevity, and demonstrate compliance to customers, thereby improving product quality and market reputation.
