Spring Universal Tester

5500 USD ($)/Unit

Get a Price/Quote

Product Details:

Specimen Size Customizable
Port Size 1/4 inch
Hardness Suitable for various spring hardness
Humidity 20% - 80% RH
Equipment Type Universal Spring Tester
Power Supply AC 220V, 50/60Hz
Gas Pressure 0.4-0.7 MPa
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Spring Universal Tester Price And Quantity

Price 5500 USD ($)/Unit
Minimum Order Quantity 1 Unit

Memory Function Up to 100 test records
Drive System Precision lead screw and stepper motor
Frame Construction Heavy-duty powder coated steel structure
Data Output Test results exportable to PC
Safety Devices Integrated emergency stop and overload alarm system
Software Optional analysis and reporting software via PC
Compliance Standard ASTM, ISO compliant testing processes
Spring Types Supported Compression, tension, torsion

Spring Universal Tester Product Specifications

Specimen Size Customizable
Port Size 1/4 inch
Hardness Suitable for various spring hardness
Capacity 500 N
Humidity 20% - 80% RH
Equipment Type Universal Spring Tester
Power Supply AC 220V, 50/60Hz
Gas Pressure 0.4-0.7 MPa
Measuring Range 0-500 N
Application Compression, tension, and fatigue tests of springs
Number of Specimens 1
Max Height 320 mm
Test Range 0-500 N
Usage Industrial/Testing Laboratory
Display Type Digital Display
Operating Voltage 220V
Test Stroke Max. 120 mm
Control Mode Digital Control
Test Width 150 mm
Machine Weight Approx. 85 kg
Interface Type USB/RS232
Frequency 50/60 Hz
Automation Grade Semi-automatic
Test Speed 10-60 mm/min adjustable
Mounting Type Bench-top
Resolution 0.01 N
Accuracy 0.5% F.S.
Features Automatic peak value hold, Test data storage, Overload protection
Response Time 10 ms
Temperature 5C - 40C

Memory Function Up to 100 test records
Drive System Precision lead screw and stepper motor
Frame Construction Heavy-duty powder coated steel structure
Data Output Test results exportable to PC
Safety Devices Integrated emergency stop and overload alarm system
Software Optional analysis and reporting software via PC
Compliance Standard ASTM, ISO compliant testing processes
Spring Types Supported Compression, tension, torsion

Spring Universal Tester Trade Information

FOB Port Shenzhen
Supply Ability 10-30 Unit Per Month
Delivery Time 1 Week
Packaging Details Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Certifications CE,ISO

Product Description

The usage:

This machine is widely used in tape,rubber,plastic,footwear,leather,apparel,fabric,paper products,pharmacy and so on,for tensile strength,tear resistance,peel strength,bend strength,shear force,etc with different fixtures according to national and international standards customer required. It can be test connected to computer with easy operation.

TECHNICAL PARAMETERS:

Test position	One
Stroke	50mm
Speed	20-90 times per minute
Counter	0-999,999 times
Weight Wood Package	30kg
Machine Dimension	(LWH) 260220420mm
Power	AC220V10%, 50/60Hz, single phase

Robust Construction for Reliable Testing

Engineered from heavy-duty powder-coated steel, the Spring Universal Tester offers long-lasting durability even under frequent use. Its rugged frame ensures stability during compression, tension, and fatigue tests, minimizing measurement errors. This robust structure makes it ideal for both industrial facilities and testing laboratories, offering confidence in performance and repeatability across a variety of spring types and specimen sizes.

Integrated Safety and Precise Control

Safety and precision are at the heart of the testers design. The emergency stop and overload alarm system help protect both operators and equipment, while the advanced digital control mode allows for accurate adjustment of test speed, stroke, and other parameters. Coupled with a response time of 10 ms and overload protection, the tester delivers reassurance and reliability, particularly in high-volume, quality-critical testing environments.

Comprehensive Data Management and Compliance

The tester supports up to 100 test record storage and enables seamless export of results to PCs via USB or RS232 interfaces. For users seeking deeper analysis, optional software provides detailed reporting capabilities. Compliance with ASTM and ISO standards ensures validated testing processes, making this equipment suitable for global markets, including dealers and distributors in China and beyond.

FAQs of Spring Universal Tester:

Q: How do I export test data from the Spring Universal Tester to my computer?

A: Test results can be easily exported to your PC using the USB or RS232 port. The tester supports data output, enabling analysis and documentation with optional reporting software.

Q: What types of spring tests can this universal tester perform?

A: This equipment accommodates compression, tension, torsion, and fatigue tests on a wide range of spring types. Its customizable specimen size features allow adaptation for various industry needs.

Q: When should I use the emergency stop feature or expect the overload alarm system to activate?

A: The integrated emergency stop is intended for immediate termination of testing during unexpected events or hazards. The overload alarm activates automatically if load levels exceed the equipments set capacity, ensuring both user safety and device protection.

Q: Where can this spring tester be installed and operated?

A: The bench-top mounting design makes it suitable for industrial testing laboratories, factories, and workshops. Its compact footprint and digital controls facilitate versatile installation within these environments.

Q: What is the process for conducting a spring test using this machine?

A: Place the spring specimen into the customizable test area, select relevant test parameters (speed, stroke, and mode) via digital control, and initiate the test. Results are then displayed digitally and can be stored or exported for further analysis.

Q: How does the tester benefit manufacturers and suppliers of springs?

A: Manufacturers, suppliers, and quality control labs benefit from precision measurements, data storage, reliable safety mechanisms, and standard compliance. These features enhance product quality validation and workflow efficiency.
