Led Dust Test Chamber
4788 USD ($)/Unit
Product Details:
- Output Programmable
- Input Power, Air supply
- Product Type Dust Test Chamber
- Usage LED, Electronics, Automotive, Electrical Products
- Efficiency High efficiency dust circulation
- Standard IEC 60529, IS 12063, JIS D0207, GB4208-93, IP5X/IP6X
- Insulation Material Polyurethane foam
- Click to View more
X
Led Dust Test Chamber Price And Quantity
- 4788 USD ($)/Unit
- 1 Unit
- 5C to 35C
- <65 dB
- 304 Stainless Steel inner chamber, powder coated steel exterior
- LED viewing light inside chamber
- Clear tempered glass with anti-fog system
- 85% RH
- Multi-directional airflow with adjustable flow rate
- Programmable timer up to 99 hours 59 minutes
- Available from 200L to 1000L
- Built-in for test object evacuation
- Double layer silicon gasket for airtight sealing
- Standardized talcum powder (0~75 m)
- Adjustable and removable
- Overload protection, emergency stop, interlock system
Led Dust Test Chamber Product Specifications
- LED, Electronics, Automotive, Electrical Products
- IEC 60529, IS 12063, JIS D0207, GB4208-93, IP5X/IP6X
- Dust Test Chamber
- Approx. 250 kg
- Standard / Customizable
- Grey
- Power, Air supply
- Polyurethane foam
- 220V / 380V customizable
- PLC Touch Screen Operation
- 220V AC, 50Hz, Single Phase
- Programmable
- Adjustable
- Customizable (e.g., 1000 x 1000 x 1000 mm)
- High efficiency dust circulation
- 2% RH and 1C
- 5C to 35C
- <65 dB
- 304 Stainless Steel inner chamber, powder coated steel exterior
- LED viewing light inside chamber
- Clear tempered glass with anti-fog system
- 85% RH
- Multi-directional airflow with adjustable flow rate
- Programmable timer up to 99 hours 59 minutes
- Available from 200L to 1000L
- Built-in for test object evacuation
- Double layer silicon gasket for airtight sealing
- Standardized talcum powder (0~75 m)
- Adjustable and removable
- Overload protection, emergency stop, interlock system
Led Dust Test Chamber Trade Information
- Shenzhen China
- 10-30 Unit Per Month
- 1 Week
- Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Product Description
Led Dust Test Chamber
Product introduce :
Led Dust Test Chamber is suitable for shell sealing performance testing products, mainly used for the standard stipulated in the protection grade of the test IP5X and IP6X two grades.Mainly is to simulate sandstorm weather on locks, LED prodcuts like solar lights, garden lights, buried lights, tunnel lights, car lights, fountain lights, the display etc the damage caused by the electricity meter and other products.
CHAMBER DESIGN FEATURES:
- Chamber material: SUS 304 stainless steel
- Transparent window is convenient to observe specimen during testing
- Blow fan adopts stainless steel shell, high sealing and wing speed, low noise
- Inside the shell is the funnel type, vibration cycle can be adjusted, dust free float in the sky falling to blowing the hole together
STANDARD FEATURES
| Item | Specification |
| Inner chamber size (L*W*H) | 1000*1000*1000mm |
| External chamber size (L*W*H) | 1200*1650*1900mm |
| Packaging dimensions (L*W*H) | 1500*1850*2100mm |
| Testing time | 0.1s 999hr, adjustable |
| Dust concentration | 2kg/m3 5kg/m3, should be replaced in every 20 tests |
| Dust type | Powdered cement, talcum powder |
| Blower | Centrifugal fan |
| Internal chamber material | SUS 304 stainless steel |
| External chamber material | Stainless steel |
| Door material | tempering glass |
| Controller | PLC controller, touch screen Blowing dust time (Stop/Blow) h/m/s Cycle time: can be adjusted Pre-set test time: 0s 999h99m99s Specimen opening: off on off |
| Power supply | single-phase, 220V 10%, 50/60Hz (can be appointed) |
| Vacuum system | Pressure gauge, air filter, Pressure regulating FRL, connecting pipe, Vacuum pump |
| Vacuum pump | 60 600L/h |
| Power socket inside chamber | Dust proof power socket for specimen opening |
| Test criteria | IEC 60529 IP5X 6X |
CHAMBER DESIGN FEATURES:
- Chamber material: SUS 304 stainless steel
- Transparent window is convenient to observe specimen during testing
- Blow fan adopts stainless steel shell, high sealing and wing speed, low noise
- Inside the shell is the funnel type, vibration cycle can be adjusted, dust free float in the sky falling to blowing the hole together.
Precision Dust Testing for Critical Applications
Our chamber ensures rigorous dust resistance testing for electronics, automotive components, and LED products. The advanced programmable controls and customizable features enable users to closely replicate real-world dust exposure conditions. All tests meet international standards, ensuring products achieve optimal ingress protection before market release.
Robust Construction and Reliable Operation
Constructed with a stainless steel interior and powder coated exterior, the chamber offers durability and resistance to corrosion. Double-layer silicon door gaskets and high-quality polyurethane insulation ensure an airtight and stable testing environment, while the adjustable/removable shelves provide flexibility for diverse product sizes.
Advanced Features for User Safety and Convenience
Safety takes precedence with integrated overload protection, emergency stop, and an automatic interlock system. The observation window is equipped with clear, anti-fog tempered glass, and interior LED lighting, enabling safe and continuous monitoring of test samples during operation without risk.
FAQs of Led Dust Test Chamber:
Q: How does the Led Dust Test Chamber maintain precise control over test conditions?
A: The chamber employs a PLC touch screen operation for intuitive programming of test duration (up to 99 hours 59 minutes), airflow rate, vacuum cycles, and lighting. Double-layer silicon gaskets, polyurethane foam insulation, and accurate humidity/temperature sensors (2% RH, 1C) assure precise and repeatable dust ingress tests.Q: What materials are used in the construction of the chamber, and how do they benefit the testing process?
A: The inner chamber is made of 304 stainless steel, while the outer shell is finished with powder-coated steel. These materials provide a corrosion-resistant and robust environment, ensuring a contaminant-free space and long-lasting performance under repeated testing cycles.Q: Where can the Led Dust Test Chamber be utilized, and what industries benefit most from it?
A: This chamber is suited for use in laboratories, quality assurance centers, and manufacturing facilities, especially within the electronics, automotive, LED, and electrical sectors. It helps verify compliance with IP5X/IP6X dust protection standards critical for product reliability.Q: When should I perform a dust ingress test, and what standards does the chamber support?
A: Dust ingress tests are recommended during product development stages or before market release to ensure compliance and durability. The chamber adheres to international standards, including IEC 60529, IS 12063, JIS D0207, GB4208-93, supporting both standard and custom test protocols.Q: What is the process for operating the dust test chamber, and how user-friendly is it?
A: Operation is straightforward: load the samples onto the adjustable shelves, program the test parameters using the PLC touchscreen, and start the test. Observation can be safely done through the anti-fog tempered glass window with internal LED illumination, and safety is ensured by emergency stop/interlock features.Q: How does the built-in vacuum pump and dust circulation system improve test efficiency?
A: The built-in vacuum pump allows for programmable evacuation of test objects, simulating real-world ingress conditions, while the multi-directional, adjustable airflow offers uniform dust distribution. This setup ensures high testing efficiency and dependability in determining product dust resistance.Tell us about your requirement
