Textile Colour Fastness To Washing Tester
1000.00 - 6500.00 USD ($)
Product Details:
- Port Size Standard Jar Size (Approx. 550 ml each)
- Test Range Up to 12 jars per batch
- Temperature up to 98C or adjustable
- Humidity Ambient
- Number of Specimens Up to 12 simultaneously
- Test Material Textile fabric, dye samples
- Specimen Size as per ISO/IS/BS standards, typically 10x4 cm
- Click to View more
X
Textile Colour Fastness To Washing Tester Price And Quantity
- 1000.00 - 6500.00 USD ($)
- 1 Set
- 40 ±2 rpm
- Approx. 14 Litres
- Immersion heater
- ISO 105 C10, IS 3361, BS 1006 C01, AATCC 61, 86 & 132
- Digital programmable, up to 999 minutes
- Over-temperature protection, automatic power-off
- Microprocessor based digital control
- 12 nos. 550 ml stainless steel jars, specimen holders, instruction manual
Textile Colour Fastness To Washing Tester Product Specifications
- Up to 12 jars per batch
- 220V/50Hz
- Stainless Steel
- Testing colour fastness of textiles to washing
- Standard Jar Size (Approx. 550 ml each)
- Approximately 100 kg
- 750 x 400 x 550 mm
- Textile Laboratory, Quality Control
- Electric
- as per ISO/IS/BS standards, typically 10x4 cm
- Ambient
- up to 98C or adjustable
- Textile fabric, dye samples
- Colour Fastness To Washing Tester
- Up to 12 simultaneously
- 40 ±2 rpm
- Approx. 14 Litres
- Immersion heater
- ISO 105 C10, IS 3361, BS 1006 C01, AATCC 61, 86 & 132
- Digital programmable, up to 999 minutes
- Over-temperature protection, automatic power-off
- Microprocessor based digital control
- 12 nos. 550 ml stainless steel jars, specimen holders, instruction manual
Textile Colour Fastness To Washing Tester Trade Information
- Shenzhen China
- 150 Set Per Month
- 15 Days
- Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
- Australia, South America, Eastern Europe, Middle East, Africa, Central America, Western Europe, Asia, North America
Product Description
We are the main manufacturer and supplier of Textile Color Fastness To Washing Tester. This material testing equipment is connected to decide the material color washing shading speed, impervious to washing, impervious to cleaning and impervious to therapist of material cotton, fleece, silk jute and concoction fiber materials. The offered range is manufactured by using optimum quality stainless steel with the help of innovative technology and latest machinery to meet client end. Also, offered range of Textile Color Fastness To Washing Tester is available with us at market leading cost.
Testing standard :
- ISO 105-C06,ISO 105-C08,ISO 105-C09,ISO 105-C10,ISO 105-D01,ISO 105-E03
- AATCC 61,190 AATCC 86,132
- M&S C04,M&S C05, M&S C10A, M&S C12A, M&S C37
- BS 1006,JIS L0844
Feature :
- To decide the Color Fastness to Washing or Dry Cleaning.
- Latest Ergonomic plan with client well disposed control board.
- Robust totally stainless steel body gives long life operations and solidness.
- Temperature upto 95oC with a Digital Temperature Controller.
- Inching office for stacking and emptying of the measuring utencils.
- 10Beakers of 550 ml. (For ISO)and 10beakers for 1200ml(For AATCC)
- Special silicon gaskets for the measuring utencils having long life.
- Touch control board furnished with ISO & AATCC testing programs for simple operation.
- No additional equipment, apparatuses, or connectors are required for 1200ml holders.
Technical Parameters :
| Number of Beakers(Test Vessels) | Total 20Nos. (10Nos.(For ISO) and 10Nos. For AATCC) |
| Standard seal for beakers | 12 no s special neoprene gaskets |
| Volume of each beaker | as per ISO:550 ml; as per AATCC:1200ml |
| Distance from shafts | 45 mm |
| Speed of rotation | 40 + 2 rpm |
| Temperature Controller | TI-LM35 type (up to 99.9oC) L/C - 0.5oC |
| Temperature Regulation | + 2.0 C (as per ISO) |
| Control mode | LCD touch panel |
| Power supply | 220V, 50Hz |
| Weight | 100 Kg |
| Dimensions | 800 x 500 x 1000 mm |
Accessories:
- Main Unit:01 No.
- Beakers (Pots):10 Nos for ISO, 10 Nos. for AATCC
- Gaskets - (Fitted in the Beakers):12 Nos.
- Stainless Steel Balls (Pack of 100):01 No.
- Measuring Plastic Beaker (100 ml):01 No.
- Beaker:10No 550ml, 10No. 1200ml
- Filter Unit - For taking out the S.S. balls from the measuring glass after testing:01 No.
- Plastic Tubing (1 Meters each) - for Outlet and Overflow Valves:01 No.
Our Services
Pre-benefit
- 24 Hours online organization for your advice.
- Help pick right model,and a movement of service,person,advise.
Focus organization
- Give you best offer
- Provide markdown for a few sets mastermind
- Do customer's request:
- Choose portion term you convenient.
After arrangement advantage
- 1 year ensure organization and all life upkeep.
- Technical Engineer are Available for oversea training.
- Free change for a couple segments
- Remote control specific direction
Other Details :
| Minimum | 1 SET |
| Delivery | 15 days after order. |
| Country | China |
| Brand Name | HD |
| Package | Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside. |
| Payment | L/C, D/P, T/T |
| Price | FOB, CIF |
Superior Colour Fastness Testing
Engineered specifically for textile laboratories, this tester offers reliable and standardized colour fastness assessments. By accommodating up to 12 specimens at once, it significantly boosts testing efficiency and accuracy. The immersion heating system ensures an even temperature distribution, critical for replicable results.
Comprehensive Control & Safety
A user-friendly microprocessor digital panel lets operators set precise rotation speeds and test durations up to 999 minutes. The system incorporates vital safety features, including over-temperature protection and automatic power-off, safeguarding both users and samples during operation.
FAQs of Textile Colour Fastness To Washing Tester:
Q: How does the Textile Colour Fastness To Washing Tester operate?
A: This instrument evaluates colour fastness by rotating up to 12 textile specimens in stainless steel jars filled with washing solutions. The jars are immersed in a water bath, heated with an immersion heater, and rotated at 40 2 rpm. Temperature and time are controlled digitally for precise, standardized testing.Q: What types of textile samples can be tested with this equipment?
A: The tester is compatible with a wide range of textiles or dyed fabric samples, typically measuring 10x4 cm as per ISO/IS/BS standards. It is designed to support rigorous testing protocols specified by various international standards.Q: When should I use this colour fastness tester in textile quality control?
A: This tester should be utilized during quality assurance processes to ensure that textile products meet industry standards for colour stability after washing. Regular testing during production or before product release is recommended.Q: Where can this instrument be installed and used?
A: The tester is built for laboratory environments such as textile testing labs, quality control departments, and research centers. Its durable stainless steel structure and compact dimensions make it ideal for professional textile laboratories and industrial settings.Q: What is the procedure for conducting a test with this machine?
A: Start by preparing textile specimens and loading them into the stainless steel jars along with the designated washing solution. Set the desired rotation speed, temperature (up to 98C), and timer on the digital panel. Once parameters are set, the jars will rotate within the heated bath for the programmed duration before automatically stopping.Q: How can users benefit from this instruments features?
A: Users benefit from high testing throughput (up to 12 jars simultaneously), accurate digital controls, and enhanced safety measures. The tester provides reliable and repeatable results crucial for compliance and product quality, reducing the risk of colour fading in finished goods.Tell us about your requirement
