Plastic Universal Testing Equipment

Plastic Universal Testing Equipment
Plastic Universal Testing Equipment
Product Code : HD-B617-1
Brand Name : HD
Product Description

Plastic Universal Testing Equipment



Description:

Plastic Universal Testing Equipment have a plastic special fixture and test trip, compared with other fixtures, fixture to increase the stripe design, better fixed inspection material to ensure accurate data.

Plastic Universal Testing Equipment can do tensile test, tear test, peel test, bond test with different clamps for plastic,rubber, tape, film and other kind of materials.

This Universal Testing Equipment uses the motor to drive screw to move fixtures. Fix sample between upper and lower fixture and pull sample by the upper fixture upward with specified speed. The load cell connecting with upper fixture will sense the force and then convert it into voltage sign to the display screen. Force value will be displayed automatically on the screen.




Benefit Features:

  1. TM 2101 intelligent automatic detection of the operating system, (can adapt to all current PC)
  2. High-tech, low noise
  3. Humanized industrial design, easy to place and transport
  4. The world famous brand core precision components
  5. Security protection system
  6. Valid test trip length (modifiable)



Applications Test Industry:
Plastic,Rubber,Film,PVC,PC,PB,and other materials.


Applications Details:

  1. Deformation under defined load: Test deformation under defined load of tested sample
  2. Load under defined deformation: Test load under defined deformation of tested sample
  3. Software can issue report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.
  4. This machine can do different test as per customer requirement such as peel test, tear test, compression test, bend test with different clamps.


Application Standard (including but not limited to...):
 ASTM,JIS,CE, ISO,EN,BS EN,SAE,FTM...etc.


Specification
:

Item

Description

Max. Force

500kg (5KN)

Load cell

Germany brand load cell for high accuracy

Control system

LCD / PC with windows 7 system

Motor

Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod

Force reading

kgf, Ibf, N, KN, T etc

Stoke

1400mm including fixture

Load cell Resolution

1/250,000

Load Precision

within ±0.5%

Test speed

0.01~500mm/min (adjustable)

Software

TM 2101

Curves display

Load- elongation, Elongation-time, Time-elongation, Stress-strain

Data display

Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc

Safety features

E-Stop

Over-load protection

Upper and lower limit switches

Load sensor with automatic retreat
